Sending Error Logs to Slack

Environment

• CentOS Linux release 7.1.1503 (Core)
• td-agent: 0.12.12
• Nginx: 1.8.0

Overview

Since Slack-based collaboration has been taking off internally
and we’ve been consolidating log management into fluentd,
I decided to give it a shot and have error logs trigger Slack notifications when something happens.

I’m envisioning a flow like the following.

Nginx error.log —> fluentd —> slack

I thought “Should I build a gem?” but there are already plenty of Slack plugins out there,
so I’ll gladly ride on their coattails!

Preparation

Make sure fluentd can access /var/log/nginx/error.log.

If you can’t tail the logs for some reason, see the following.

fluentd設定ハマった所あるある - 長生村本郷Engineers'Blog

以下に移行しました。 kenzo0107.github.io

fluentd Plugins to Use

• sowawa/fluent-plugin-slack
• sonots/fluent-plugin-record-reformer
• fluent/fluent-plugin-rewrite-tag-filter

td-agent.conf Configuration

error.log Format Configuration

• Assume that Nginx’s error logs are formatted and output as follows.

2015/11/18 18:01:47 [error] 23029#0: *9086 open() "/var/golang/src/img/tmp.png" failed (2: No such file or directory), client: ***.**.**.****, server: hogehoge.jp, request: "GET /img/tmp.png HTTP/2.0", host: "hogehoge.jp", referrer: "http://hogehoge.jp"

• fluentd format configuration

format /^(?<time>.+) \[(?<level>[^\]]+)\] *(?<message>.*)$/

With the format configuration above, you can extract the data in a key : value structure as follows.

time : 2015/11/18 18:01
level : error
message : or] 23029#0: *9086 open() "/var/www/html/img/tmp.png" failed (2: No such file or directory), client: ***.**.**.****, server: hogehoge.jp, request: "GET /img/tmp.png HTTP/2.0", host: "hogehoge.jp", referrer: "http://hogehoge.jp"

Depending on the configuration, the notifications didn’t come through properly and I got stuck for a bit. (sweat)

Rewriting the tag Name

We rewrite the tag based on the key:value extracted above.

In the example below,
when level is error, the tag is rewritten to slack.error.${tag} (slack.error.nginx.error).
The same goes for warn and fatal.

<match nginx.error>
  type rewrite_tag_filter
  rewriterule1 level error slack.error.${tag}
  rewriterule2 level warn slack.warn.${tag}
  rewriterule3 level fatal  slack.fatal.${tag}
</match>

You can also match cases where the value extracted in message

contains a specific string.

e.g.) When message contains a string starting with “PHP Fatal Error”, rewrite it to slack.fatal.${tag}.

<match nginx.error>
  type rewrite_tag_filter
  rewriterule1 level error slack.error.${tag}
  rewriterule2 level warn slack.warn.${tag}
  rewriterule3 level fatal  slack.fatal.${tag}

  rewriterule4 message ^PHP Fatal Error.*$ slack.fatal.${fatal}    # added
</match>

Adding a Field

• Adding source_id

In addition to time, level, and message, we add source_id.
In the example below, tag_suffix[1] is specified for source_id.

<match slack.**>
  type record_reformer
  tag reformed.${tag}
  <record>
    source_id ${tag_suffix[1]}
  </record>
</match>

About tag_suffix

If the tag is reformed.slack.error.nginx.error,
the specification is as follows.

tag_suffix[0] → reformed.slack.error.nginx.error
tag_suffix[1] → slack.error.nginx.error
tag_suffix[2] → error.nginx.error

tag_suffix[-1] → error
tag_suffix[-2] → nginx.error

Slack Notification

• Set the Webhook URL from an Incoming Webhook

<match reformed.slack.**>
  type slack
  webhook_url https://hooks.slack.com/services/xxxxxxxxx/xxxxxxxxx/xxxxxxxxxxxxxxxxxxxxxxxx
  channel flag_production
  username fluentd
  title_keys source_id
  title %s
  color danger
  flush_interval 5s
</match>

Notification Result

A Side Note

Even if you send notifications to Slack, it often happens that people don’t check work messages on their days off,
so there’s also a plugin that notifies you by phone via Twilio.

y-ken/fluent-plugin-twilio

It’s a paid service provided by KDDI Web Communications Inc.
It’s relatively inexpensive, so please consider adopting it.

Twilio Pricing Table

twilio price

It’s nice that the old “Sorry, I didn’t see the email 💦”
situations seem like they’ll be a thing of the past.

That’s all.
